The HG-JR353: The IP67 rating means the motor is dust-tight and protected against temporary immersion — a fit for washdown environments or dusty plant floors. The 51 A peak allows short-duration overloads beyond the 17 A continuous rating, useful during acceleration or momentary high-torque demands.
Mitsubishi HG-JR353 AC Servo Motor, 3.5 kW, IP67
MPNHG-JR353
Mitsubishi HG-JR353, AC Servo Motor, 3.5 kW, 3000 r/min, IP67, 17 A rated, 51 A peak.
$1,243.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Enclosure | IP67 |
| Rated speed | 3000 r/min |
| Power supply | 200 V |
| Product type | AC Servo Motors |
| Rated output | 3.5 kW |
| Current | 17 A |
| Maximum current | 51 A |
| Rotational spped | 6000 rpm max |
Product details
Frequently asked questions
What is the enclosure rating of the HG-JR353?
IP67, meaning it is dust-tight and protected against temporary immersion in water.
What are the key electrical ratings of the HG-JR353?
Continuous 17 A, peak 51 A, at 3.5 kW and 3000 r/min rated speed.
MPN
HG-JR353
