Mitsubishi Electric LD75P1-CM — Motion Controllers

Mitsubishi LD75P1-CM Positioning Module, 1 Axis 200K pps

MPNLD75P1-CM

Mitsubishi LD75 series, programmable controller positioning module, LD75P1-CM, 1 axis, 200K pulses/s max output, 600 data/axis.

$441.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

LD75P1-CM — Identification
ParameterValue
Product typeProgrammable Controller
LD75P1-CM — Other specifications
ParameterValue
Positioning data600 data/axis
Max. output pulses200K pulses/s
Number of control axes1 axis
Max. connection distance2m

Product details

The Mitsubishi LD75P1-CM is a single-axis positioning module from the LD75 series, rated for 200K pulses/s output and carrying 600 positioning data points per axis. It connects to a servo drive via open-collector output up to 2 m cable distance. This is a current-production part with a typical lead time of one to ten working days, which means it's readily specified for new builds or spares without obsolescence risk.

The 200K pulses/s output and 2 m cable limit restrict this module to short-range open-collector positioning. 600 data/axis means you can store 600 target positions, speeds, or dwell times per axis on the module itself. That's enough for a moderate sequence; beyond that, you'd need to stream from the PLC, which adds scan-time jitter.

Frequently asked questions

What is the closest second-source module if I need more axes?

The LD75P2-CM (2 axes) and LD75P4-CM (4 axes) are the same series with identical output pulse rate and cable limits. They are functional upgrades, not direct substitutes — swapping axis count requires program changes, not just a module swap.
