Mitsubishi Electric MR-J4-40A1-RJ — Servo Drives

Mitsubishi MR-J4-40A1-RJ Servo Amplifier, 0.4 kW, 1-Phase 10

MPNMR-J4-40A1-RJ

Mitsubishi MR-J4-40A1-RJ servo amplifier, 0.4 kW rated output, 1-phase 100 VAC input, full closed-loop control.

$1,435.19Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

MR-J4-40A1-RJ — Specifications
ParameterValue
Weight0.69 kgs
InterfaceGENERAL PURPOSE
Power supply1 PHASE, 100 VAC
Rated output0.4 KW OUTPUT
Special specFULL CLOSED LOOP CONTROL

Product details

The MR-J4-40A1-RJ is a Mitsubishi servo amplifier rated for 0.4 kW output on a 1-phase 100 VAC supply, with full closed-loop control. That means it drives a servo motor while continuously comparing commanded vs. actual position — useful for applications where the machine needs to hold position against a load or compensate for mechanical backlash, like a cut-off knife on a paper winder or a tension-register roll.

The FX5-80SSC-S is a MELSEC iQ-F motion module, not a servo amplifier — it handles up to 8 axes of positioning logic but needs an external amplifier and motor. The MR-J4-40A1-RJ is the power stage: it takes the command signals and drives the motor. They are not drop-in interchangeable; the FX5-80SSC-S would sit in the PLC rack, the MR-J4-40A1-RJ in the cabinet near the motor.

Frequently asked questions

What are the key ratings for the MR-J4-40A1-RJ?

Rated output is 0.4 kW on a 1-phase 100 VAC supply, with full closed-loop control. Weight is 0.69 kg.

MPN
MR-J4-40A1-RJ
