Mitsubishi Electric MR-JE-10A

Mitsubishi MR-JE-10A Servo Amplifier, 100 W, 200 VAC, 1.1 A

MPN MR-JE-10A

Mitsubishi Electric MELSERVO-JE series, MR-JE-10A servo amplifier, 100 W rated output, 200 VAC 1/3-phase input, 1.1 A rated current, IP20, built-in dynamic brake.

$84.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

MR-JE-10A specifications
ParameterValue
Product typeMR-JE-_A Servo Amplifier
Current1.1 A
Weight0.8 Kg

Product details

The Mitsubishi MR-JE-10A is a 100 W servo amplifier from the MELSERVO-JE series, designed for general-purpose motion control. It accepts 1-phase or 3-phase 200 VAC to 240 VAC input at 50/60 Hz and delivers a rated current of 1.1 A. The built-in dynamic brake means you don't need an external braking resistor for stopping the motor under normal deceleration — a real space saver in a crowded cabinet.

The 1.1 A rated current tells you the continuous output the amplifier can support at its 100 W rating. Match this to a servo motor whose rated current falls at or below 1.1 A — oversizing the motor will trip the drive on overload. The sine-wave PWM control method gives smooth torque at low speeds, which matters for positioning applications like pick-and-place or indexing conveyors. IP20 (open type) with natural cooling requires a clean, ventilated enclosure.

MPN
MR-JE-10A
