The MR-JE-20C is a single-axis digital AC servo amplifier rated for 0.2 kW continuous output. It accepts 200-240 VAC on either single-phase or three-phase supply, giving flexibility for panel layouts where three-phase is available or only single-phase is run to the cabinet. The 0.2 kW capacity suits small positioning axes — pick-and-place, conveyor indexing, or light rotary tables — where the motor frame is typically a 50-60 mm square.
Mitsubishi MR-JE-20C Digital AC Servo Amplifier, 0.2 kW
MPNMR-JE-20C
Mitsubishi MR-JE series, Digital AC-Servo Amplifier, MR-JE-20C, 0.2 kW rated capacity, 200-240 VAC single/three-phase supply, 1 axis, 168 x 50 x 135 mm.
$350.00 – $839.51Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Product type | Digital AC-Servo Amplifier |
| Parameter | Value |
|---|---|
| Depth | 135 mm |
| Width | 50 mm |
| Height | 168 mm |
| Weight | 0.8 Kg |
| Estimated lead | 1 - 10 working days. |
| Number of axes | 1 |
| Rated capacity | 0.2 kW |
| Power supply 1 phase | 200-240 VAC |
| Power supply 3 phase | 200-240 VAC |
Product details
Frequently asked questions
What are the power supply requirements for MR-JE-20C?
It accepts 200-240 VAC on either single-phase or three-phase input. Single-phase is common for smaller cabinets; three-phase gives better DC-bus regulation under load.
What is the rated capacity of MR-JE-20C?
Rated continuous output is 0.2 kW. That drives a 200 W servo motor — typical for small indexing or positioning axes.
Where can I buy MR-JE-20C?
Sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time.
MPN
MR-JE-20C
