Mitsubishi Electric Q172CPUN — PLCs (Programmable Logic Controllers)

Mitsubishi Q172CPUN Motion Controller, 4-Axis

MPNQ172CPUN

Mitsubishi Q Series Motion Controller, Q172CPUN, 4-axis linear/circular/helical interpolation, 1.14 A at 5 VDC.

$964.21 – $1,589.00Ref. price · indicative, final on quote
Mitsubishi Electric Q172CPUN datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

Q172CPUN — Mechanical
ParameterValue
Weight0.22 Kg
Q172CPUN — Other specifications
ParameterValue
CompensationBacklash compensation, Electronic gear
Product typeMotion Controller
Control modesPTP(Point to Point) control, Constant-speed positioning, High-speed oscillation control
Dimensions (LxWxH)11.43cm x 2.74cm x 9.8cm
Programming languageDedicated instruction (EIA language)
Interpolation functionsLinear interpolation (Up to 4 axes), Circular interpolation (2 axes), Helical interpolation (3 axes)
Internal current consumption(5VDC) [A]1.14

Product details

Motion Controller for Multi-Axis Positioning

The Q172CPUN is a Mitsubishi Q series motion controller supporting PTP (point-to-point) control, constant-speed positioning, and high-speed oscillation control. Its interpolation function handles up to 4 axes for linear moves, 2 axes for circular arcs, and 3 axes for helical paths — covering the common motion profiles in pick-and-place, packaging, and machine tool applications. Backlash compensation and electronic gear are built in, so the controller can correct for mechanical hysteresis directly without an external compensation module.

Rack Integration and Power Budget

The Q172CPUN draws 1.14 A from the backplane supply. Ensure the rack's total load stays within the power module's limit.

Frequently asked questions

What control modes and interpolation does the Q172CPUN support?

The controller supports PTP (point-to-point), constant-speed positioning, and high-speed oscillation control. Interpolation includes linear up to 4 axes, circular up to 2 axes, and helical up to 3 axes.

Can the Q172CPUN drop into a panel originally specified for the FX5-8EX/ES?

No, the FX5-8EX/ES is a MELSEC iQ-F series DC input module and is not a motion controller. The Q172CPUN is a Q series motion controller and requires a Q series base rack; wiring and form factor are entirely different.

MPN
Q172CPUN
