What it is and what it does
The Mitsubishi Q173DPX is a 16-point NPN transistor output module designed for the MELSEC Q series servo drive and motion control systems. It provides discrete control signals to actuators, solenoids, or indicator lamps within a coordinated motion axis setup. The module occupies a slot on the Q-series backplane and is driven by the motion CPU or sequential program.
