Mitsubishi Electric QD77MS2 Simple Motion Module, PLC I/O & Expansion Modules, 9cm x 2.74cm x 9.8cm, 0.6 A DC 5 V internal current consumption, 0.15 Kg.
| Parameter | Value |
|---|---|
| Weight | 0.15 Kg |
| Dimensions (LxWxH) | 9cm x 2.74cm x 9.8cm |
| DC 5 v internal current consumption [A] | 0.6 |
The Mitsubishi Electric QD77MS2 is a Simple Motion Module that lives in the PLC I/O & Expansion Modules category — it's the motion control brain for a Mitsubishi PLC rack, handling coordinated axis moves without tying up the main CPU cycle.
Internal current consumption is 0.6 A at DC 5 V — that's the load the rack power supply sees from this slot alone, so add it into your backplane budget before you fill the remaining slots.
The module draws 0.6 A from the DC 5 V backplane supply. This is the power budget you need to reserve in the rack power supply for this slot.
No — the FX2N-20GM is a standalone positioning unit with a separate DC 24 V external supply and open-collector pulse outputs, while the QD77MS2 is a Q-series backplane module drawing 0.6 A at DC 5 V. The form factor, power supply, and wiring interface are different; a panel rework is required.
The module dimensions are 9 cm by 2.74 cm by 9.8 cm, with a net weight of 0.15 Kg and a shipping weight of 1.5 Kg including packaging.
