Mitsubishi Electric R64P — PLC I/O & Expansion Modules

Mitsubishi R64P IQ-R Power Supply, 9A 5VDC

MPNR64P

Mitsubishi MELSEC iQ-R Series, Power Supply Module, R64P, 100-240 VAC input, 5 VDC output at 9 A.

$261.62 – $311.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

R64P — Identification
ParameterValue
TypeIQ-R SERIES
R64P — Other specifications
ParameterValue
Dimensions5x3x6 in
Weight0,46
Current typeAC
Power supply100-240
Output, current typeAC
Dimension (W x h x d)54,6 x 98 (106) x 110
Output current 5V9

Product details

R64P is the power supply module for the MELSEC iQ-R rack. Accepts 100-240 VAC and delivers 5 VDC at 9 A. The module occupies the leftmost slot and supplies backplane power to CPU and I/O modules. Verify total backplane load does not exceed the 9 A output; the R61P sibling outputs 6 A for lower-demand configurations.

Lead time is typically quoted per request.

Frequently asked questions

What is R64P's listed type (IQ-R SERIES) on this component line?

It is part of the MELSEC iQ-R Series, confirmed by the type field.

Will R64P drop into a panel that was specified around R61P without rewiring?

Yes. Both modules share the same mounting dimensions (54.6 x 106 x 110 mm) and backplane connector. The R64P provides higher output current (9 A vs 6 A), so no panel rework is needed, but verify the increased load is acceptable for your system.

MPN
R64P
