The 3G3MX2A4007E: This Omron 3G3MX2-A4007-E frequency inverter is sized for a 0.75 kW constant-torque motor on a 380-480 V three-phase supply, with an output frequency range up to 1000 Hz for high-speed spindle or centrifuge applications. Variable-torque loads (fans, pumps) can draw up to 1.5 kW from the same drive, giving some headroom on the BOM line for mixed duty cycles.
3G3MX2A4007E Omron 3G3MX2-A4007-E Frequency Inverter, 0.75 k
MPN3G3MX2A4007E
Omron MX2 series, frequency inverter, 3G3MX2-A4007-E, 0.75 kW constant / 1.5 kW variable torque, 3-phase 380-480 VAC, IP20.
$281.94Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Specifications
| Parameter | Value |
|---|---|
| IP rating | IP20 |
| Torque | 0.75 Kw |
| Manufacture | Omron |
| Voltage out | 3 Phase/380 … 480 V AC |
| Frequency | 1000 |
| Product type | Frequency Inverter |
| Dimensions_text | 108 x 128 x 170,5 mm |
| Supply voltage | 480 |
| Switching current | 3.4 |
| Operating temperature high | -10 … 50 °C |
Product details
Frequently asked questions
What are the key ratings for 3G3MX2A4007E?
It is a 0.75 kW constant-torque / 1.5 kW variable-torque drive, 3-phase 380–480 VAC input, IP20, rated output current 3.4 A, frequency range up to 1000 Hz.
What is the difference between 3G3MX2A4007E and 3G3MX2-A4007-E?
There is no functional difference; the two strings refer to the same part – 3G3MX2A4007E is the condensed order code, 3G3MX2-A4007-E is the manufacturer's dash-formatted model number. They are interchangeable on the BOM line.
Will this drive drop into a panel originally specified with 3G3MX2-A4007-E?
Yes, they are the same product – the dash-free and dash-formatted strings identify the same Omron MX2 inverter. No rewiring or adaptation needed.
MPN
3G3MX2A4007E
