Omron CJ1W-OD213 — PLCs (Programmable Logic Controllers)

Omron CJ1W-OD213 Output Module, 16 Solid State, Screw Termin

MPNCJ1W-OD213
End of Life

Omron CJ1W-OD213, CJ series, 16-point transistor output module, screw terminal, DIN rail mount, solid state outputs.

$198.12 – $486.56Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

CJ1W-OD213 — Identification
ParameterValue
SeriesCJ1W
CJ1W-OD213 — I/O
ParameterValue
Outputs (count and type)16 - Solid State
CJ1W-OD213 — Mechanical
ParameterValue
Mounting typeDIN Rail
Weight0.243 lb (110.22 g)
Termination styleScrew Terminal
CJ1W-OD213 — Approvals
ParameterValue
Approvals / certificationsCE, Lloyd, NK
CJ1W-OD213 — Other specifications
ParameterValue
TypeOutput Module

Product details

Integrator note: what fits, what doesn't

CJ1W-OD213 is a 16-point transistor output module for the Omron CJ Series PLC backplane. Solid state outputs paired with screw terminals mean no relay replacement schedule but watch the common wiring: each group of four outputs shares a common terminal. DIN rail mounted, clips into the CJ CPU rack or expansion rack. Need a quick BOM match: 16 outputs, screw termination, CJ backplane — this fits.

Screw terminals accept ferrule or solid wire; DIN rail mount occupies one slot on the CJ backplane. Approvals CE, Lloyd, NK cover EU, marine, and Korean installations.

Frequently asked questions

What type of module is the CJ1W-OD213?

It is a 16-point transistor output module (solid state) with screw terminals, for the Omron CJ Series PLC.

What series does the CJ1W-OD213 belong to?

CJ1W series, compatible with Omron CJ1 and CJ2 backplanes.

Will the CJ1W-OD213 drop into a panel specified for the CP2E-S40DT1-D?

No. The CJ1W-OD213 uses the CJ backplane form factor, not the CP2E built-in CPU layout. They are mechanically and electrically different—no direct drop-in without rewiring and rack change.

What compliance documentation does Omron provide for the CJ1W-OD213?

The module carries CE, Lloyd (marine), and NK (Korean register) approvals. RoHS and REACH declarations are typically included in Omron's standard compliance documentation.

MPN
CJ1W-OD213
