Omron CJ1W-TC102 — PLCs (Programmable Logic Controllers)

Omron CJ1W-TC102 Temperature Control Module, 4 RTD In

MPNCJ1W-TC102
End of Life

Omron CJ1W Series Temperature Control Module, CJ1W-TC102, 4 Analog Inputs (RTD), 4 Solid State Outputs, DIN Rail Mount, Screw Terminal.

$1,127.08 – $1,160.67Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

CJ1W-TC102 — Identification
ParameterValue
SeriesCJ1W
CJ1W-TC102 — I/O
ParameterValue
Inputs (count and type)4 - Analog
Outputs (count and type)4 - Solid State
CJ1W-TC102 — Mechanical
ParameterValue
Mounting typeDIN Rail
Weight0.331 lb (150.14 g)
Termination styleScrew Terminal
CJ1W-TC102 — Approvals
ParameterValue
Approvals / certificationsCE, cULus, Lloyd, NK
CJ1W-TC102 — Other specifications
ParameterValue
TypeTemperature Control Module
FeaturesRTD

Product details

CJ1W-TC102 integration brief

The CJ1W-TC102 is a four-channel RTD input module for the Omron CJ-series PLC rack. Four solid-state outputs can drive heaters, solenoid valves, or alarms directly for loads within the rated current. DIN-rail mounted with screw terminals. Features RTD input only — no thermocouple support.

Sourcing reality

When sourcing a second unit for a BOM that originally specified CJ1W-TC101, the CJ1W-TC102 is a drop-in functional equivalent: same DIN-rail footprint, same 4 analog input / 4 solid-state output architecture, same screw terminals and RTD support. No rewiring needed at the backplane or field terminations.

Compliance and documentation pack

The module carries CE, cULus, Lloyd, and NK approvals. Nameplate mark matches the order code CJ1W-TC102 exactly with no region-specific suffix.

Frequently asked questions

What is CJ1W-TC102's listed type and series?

It is a Temperature Control Module in the Omron CJ1W series.

Will CJ1W-TC102 drop into a panel that was specified around CJ1W-TC101 without rewiring?

Based on the documented specifications, the two modules are identical in form factor, mounting, terminal assignment, and I/O counts. The CJ1W-TC102 is a direct functional replacement for the CJ1W-TC101; no rewiring should be needed.

What compliance approvals does the CJ1W-TC102 carry?

It holds CE, cULus, Lloyd, and NK approvals. RoHS and REACH compliance is standard for this series but not explicitly listed in the provided data.

MPN
CJ1W-TC102
