Omron CJ2H-CPU65

Omron CJ2H-CPU65 PLC CPU Module, 160K Words, Active

MPN CJ2H-CPU65
Active

Omron CJ2H-CPU65, CJ2H series PLC CPU, 160K words memory, RS-232C / USB, expandable to 40 modules (3 racks), active.

$2,566.00 – $4,714.23 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

CJ2H-CPU65 specifications
ParameterValue
SeriesCJ2 H
Display typeNo Display
ProtocolRS-232C, USB
MountingDIN Rail
Temp operating max55 °C
Temp operating min0 °C
Weight0.419 lb (190.06 g)
PackageBox

Product details

The Omron CJ2H-CPU65 is the CPU unit of the CJ2H series, sized for mid-range machine control with 160K words of program memory. It supports up to 40 modules across three racks, giving room for substantial I/O and specialty modules without a larger controller. Built-in RS-232C and USB ports handle programming via CX-One and serial device connectivity. Battery backup protects user programs and retained data during power-down, so the CPU restarts with no external memory reload in most applications. The module mounts on DIN rail, operates from 0°C to 55°C, and carries CE, cULus, Lloyd, and NK approvals.

The listed approvals (CE, cULus, Lloyd, NK) cover the major marine and industrial safety standards. For internal compliance documentation such as RoHS or REACH declarations, request through the distributor – the approval listing is a strong indicator of full regulatory status.

MPN
CJ2H-CPU65
