Omron CJ2M-MD212, pulse/counter I/O module, 10 PNP inputs, 6 PNP outputs, MIL connector, 100 kpps.
| Parameter | Value |
|---|---|
| Connector type | 1 x MIL |
| Digital input type | PNP |
| Encoder input type | 24 VDC or Line driver |
| Maximum input frequency | 100 kpps |
| Maximum output frequency | 100 kpps |
| Digital input | 10 |
| Digital output | PNP |
| Digital outputs | 6 |
| High-speed counter | Yes |
The Omron CJ2M-MD212 is a pulse/counter I/O module for the CJ2M CPU rack, offering 10 PNP digital inputs and 6 PNP digital outputs on a single MIL connector. Both input and output channels support high-speed pulse counting or PWM generation up to 100 kpps, with encoder inputs accepting 24 VDC or line-driver signals.
It has 10 digital inputs, all PNP type.
The module uses a single MIL connector for both inputs and outputs.
