Omron CP1E Series, CP1E-E10DT1-A, Compact PLC, 6 Digital Inputs, 4 Solid-State Outputs, 100-240VAC, 2K Words Memory.
Omron CP1E-E10DT1-A PLC, 6 Digital Inputs 4 Solid-State Outp
MPNCP1E-E10DT1-A
Active
Omron CP1E Series, CP1E-E10DT1-A, Compact PLC, 6 Digital Inputs, 4 Solid-State Outputs, 100-240VAC, 2K Words Memory.
$106.00 – $317.27Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Series | CP1E |
I/O
| Parameter | Value |
|---|---|
| Inputs (count and type) | 6 - Digital |
| Outputs (count and type) | 4 - Solid State |
| Expandable | Non-Expandable |
Electrical
| Parameter | Value |
|---|---|
| Supply voltage | 100 ~ 240VAC |
Environmental
| Parameter | Value |
|---|---|
| Operating temperature range | 0°C ~ 55°C |
Mechanical
| Parameter | Value |
|---|---|
| Mounting type | Chassis Mount, DIN Rail |
| Weight | 0.661 lb (299.82 g) |
Approvals
| Parameter | Value |
|---|---|
| Approvals / certifications | CE, cULus, Lloyd, NK |
Other specifications
| Parameter | Value |
|---|---|
| Software | CX-One |
| Memory size | 2K Words |
| Display type | No Display |
| Communications | USB |
Product details
Frequently asked questions
Will CP1E-E10DT1-A fit in a panel specified for CP1L-L10DT-A without rewiring?
Yes, the chassis footprint, DIN rail mounting, and I/O counts are identical, so existing wiring will match. However, the CP1E is non-expandable and lacks battery backup.
What compliance approvals does this part carry?
It is approved under CE, cULus, Lloyd, and NK. RoHS and REACH are not listed in the available data and should be verified with the supplier.
MPN
CP1E-E10DT1-A
