Omron CP2E series I/O module, 18 digital inputs, 12 relay outputs, 24VDC supply, screw terminal, DIN rail mount.
| Parameter | Value |
|---|---|
| Series | CP2E |
| Parameter | Value |
|---|---|
| Inputs (count and type) | 18 - Digital |
| Outputs (count and type) | 12 - Relay |
| Parameter | Value |
|---|---|
| Supply voltage | 24VDC |
| Parameter | Value |
|---|---|
| Operating temperature range | -20°C~60°C |
| Parameter | Value |
|---|---|
| Mounting type | DIN Rail |
| Termination style | Screw Terminal |
| Parameter | Value |
|---|---|
| Type | Input, Output (I/O) Module |
CP2E-N30DR-D is an active I/O module from Omron's CP2E series. It gives you 18 digital inputs and 12 relay outputs on a single DIN-rail unit, running on 24VDC. The screw terminals keep wiring straightforward for panel builders. This is a current-production part, so no last-time-buy scramble here — it's specified into the BOM without lifecycle risk.
It is an Input, Output (I/O) Module belonging to the CP2E series.
Mechanically yes — same housing, mounting, and screw terminals — but the output type differs (relay vs. solid state). If the original design relied on fast transistor switching, the relay outputs may not meet performance. Rewiring of output circuits is not needed; the terminal assignments are the same, but the load characteristics may require control logic changes.
