Omron CRT1B series output module, CRT1B-OD02S-1, 2 solid-state outputs, IP20, CE, DIN rail or chassis mount, rectangular connector and wire leads termination.
| Parameter | Value |
|---|---|
| Series | CRT1B |
| Type | Output Module |
| Compatible with | CJ, CS, NJ Series |
| Parameter | Value |
|---|---|
| Outputs and output technology | 2 - Solid State |
| Parameter | Value |
|---|---|
| Operating temperature range | -10°C ~ 55°C |
| Parameter | Value |
|---|---|
| Mounting type | Chassis Mount, DIN Rail |
| Termination style | Rectangular Connector, Wire Leads |
| Parameter | Value |
|---|---|
| Approvals / certifications | CE |
| Parameter | Value |
|---|---|
| Weight | 0.13 lb (58.97 g) |
| IP rating | IP20 |
Terminations are a rectangular connector with wire leads — strip, insert, clamp. No screw terminal torque to chase. The solid-state outputs are inherently fast and silent, but verify your load current stays within the module's maximum — the evidence doesn't specify a per-point current, so check the full datasheet for your load type.
It is a 2-output solid-state module with IP20 protection, mounts on DIN rail or chassis, terminates with a rectangular connector and wire leads, operates from -10°C to 55°C, and is CE approved.
CE is the only approval agency listed. Other marks (RoHS, UL, etc.) are not specified on this listing.
