The Omron CS1W-BC032 is a 3-slot backplane that carries the CPU and up to two I/O or specialty modules in a CS1 rack. It’s part of the CS1W series, built for the CS1 PLC line — nothing fancy, just a passive bus board that holds the rack together.
Slot-count choices: 2-slot vs 3-slot vs 8-slot
The BC032 is a 3-slot backplane.
Production status and sourcing
It’s a stocked item we quote to order. If you’re freezing a BOM, we confirm lead times against an RFQ.
Mounting and fit
Mounts directly into a CS1 rack. The backplane itself has no active components — it’s a passive bus board. Keep the area around the slots clear for module insertion and cable routing. Out here in the grease, a clean slot is a happy slot.
