Omron CS1W series, programming cable, D-Sub both ends, 19.69 ft, CE, bulk.
| Parameter | Value |
|---|---|
| Series | CS1W |
| Parameter | Value |
|---|---|
| Approvals / certifications | CE |
| Parameter | Value |
|---|---|
| Length | 19.69' (6.00m) |
| Specifications | Programming |
| Control side connection | D-Sub Connector |
| Process side connection | D-Sub Connector |
Omron CS1W-CN626 is a 19.69 ft (6 m) programming cable with D-Sub connectors on both ends, purpose-built for the CS1 series PLCs. You use it to link a laptop or programmer to the peripheral port — that 6 m run covers the distance from the cabinet door to a desk without an extension. CE marked, so it clears EU panel compliance out of the box.
Product status is Active per Omron's lifecycle record — still orderable and supported.
The CS1W-CN227 has the same D-Sub connectors on both ends and the same CS1W series compatibility, but its length is 6.56 ft (2 m) instead of 19.69 ft (6 m). If the shorter reach works for your run, it is a direct swap.
19.69 ft (6.00 m) measured from connector face to connector face.
Yes, the connectors are identical D-Sub pinouts on both ends. The only difference is the longer cable length; no rewiring needed.
