Omron CS1W-PMV01 — PLCs (Programmable Logic Controllers)

Omron CS1W-PMV01 Output Module, 8 Analog, Backplane, 0-55°C

MPNCS1W-PMV01
End of Life

Omron CS1W Series, Output Module – Analog, 8 channels, Screw Terminal, Backplane Mount, CE, cULus, 0-55°C.

$2,106.93 – $2,210.81Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

CS1W-PMV01 — Identification
ParameterValue
SeriesCS1W
CS1W-PMV01 — I/O
ParameterValue
Outputs (count and type)8 - Analog
CS1W-PMV01 — Environmental
ParameterValue
Operating temperature range0°C ~ 55°C
CS1W-PMV01 — Mechanical
ParameterValue
Mounting typeBackplane
Weight0.984 lb (450 g)
Termination styleScrew Terminal
CS1W-PMV01 — Approvals
ParameterValue
Approvals / certificationsCE, cULus
CS1W-PMV01 — Other specifications
ParameterValue
TypeOutput Module

Product details

Module overview — integrator check

The Omron CS1W-PMV01 is a 8-channel analog output module for CS Series controllers. Mounts directly on the backplane and terminates through screw terminals. Rated for a 0°C to 55°C cabinet ambient. The module carries CE and cULus approvals, making it usable in both European and North American panel builds. While physically identical to the CS1W-DA08C and CS1W-DA08V, this variant omits the marine (NK) approval – a point to confirm if the machine will see a classification society survey.

The CS1W-PMV01 shows an active lifecycle status. No end-of-life notification or last-time-buy window is in effect. This unit can be specified into new BOMs with confidence that production will support the build.

Mounting and wiring integration

Backplane mount for CS Series racks; screw terminals accept wire via Phillips clamp. Analog scaling set in CX-Programmer I/O table, no DIP switches; 8 channels share common terminal block, power from backplane.

Frequently asked questions

What is the closest functional alternative – CS1W-DA08C?

The CS1W-DA08C and CS1W-DA08V are the closest analogues: same 8 analog outputs, same physical footprint, same backplane and terminal style. The sole difference is that the DA08C and DA08V carry additional NK (marine) approval, which the PMV01 lacks. For land-based installations the PMV01 is a direct functional equivalent.

Will CS1W-PMV01 drop into a panel wired for CS1W-DA08C without rewiring?

Yes, the two modules share identical backplane slot positions, terminal assignments, and wiring layouts. No rewiring or retermination is required. The only caveat is if the original panel specification required marine (NK) classification – the PMV01 does not carry NK approval.

What compliance documentation does Omron provide for CS1W-PMV01?

The module is listed with CE and cULus approvals. RoHS and REACH declarations are standard for CS Series products. No marine (NK, Lloyd's) certification is available on this variant.

What is the operating temperature range?

Rated for 0°C to 55°C ambient cabinet temperature. This covers most indoor industrial control panels but does not extend to high-heat zones like furnace areas or direct sunlight.

MPN
CS1W-PMV01
