Omron E2A3-S08KS03-WP-C2 2M inductive proximity sensor, M8 shielded, NPN NC, 3 mm sensing distance, 12-24 VDC, 2m PVC cable, stainless steel housing.
| Parameter | Value |
|---|---|
| Sensing distance | 3 mm |
| Parameter | Value |
|---|---|
| Supply voltage | 12 to 24 VDC |
| Connection / connector | PVC cable |
| Parameter | Value |
|---|---|
| Size | M8 |
| Parameter | Value |
|---|---|
| Output | NPN |
| Mounting | Bracket with 8 mm mounting hole or M8x1 threaded hole. |
| Shielded | Shielded |
| Operation | NC |
| Case material | Stainless steel |
| Overall length | 40 |
| Threaded length | 27 |
This Omron E2A3-S08KS03-WP-C2 2M is a shielded M8 inductive proximity sensor with NPN output and normally-closed operation, rated for a 3 mm sensing distance on 12 to 24 VDC supply. Stainless steel housing and PVC cable suit washdown environments; bracket or M8x1 threaded mounting provides installation options. Lifecycle stage is current production.
It is an M8 shielded housing, 40 mm overall length, 27 mm threaded length.
NPN output, normally-closed (NC) operation.
