Omron E2B-M12KS02-WP-C1 5M — Proximity Sensors

Omron E2B-M12KS02-WP-C1 5M Shielded NPN Proximity 2mm

MPNE2B-M12KS02-WP-C1 5M

Omron E2B Series, M12KS02-WP-C1 5M, Shielded Inductive Proximity Sensor, NPN Output, 2mm Sensing Distance, 5m PVC Cable.

$8.89Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

E2B-M12KS02-WP-C1 5M — Sensing
ParameterValue
Sensing distance2mm sensing distance
E2B-M12KS02-WP-C1 5M — Output
ParameterValue
Operation modeNormally open
E2B-M12KS02-WP-C1 5M — Mechanical
ParameterValue
Cable length5 meter cable
E2B-M12KS02-WP-C1 5M — Other specifications
ParameterValue
ShieldShielded
Weight0.45 kgs
Housing size12 mm diameter
Barrel lengthShort body
Connection typePre-wired, PVC
Power source and outputNPN
Housing shape and materialCylindrical, metric thread, brass

Product details

The Omron E2B-M12KS02-WP-C1 5M is a shielded M12 inductive proximity sensor with a 2mm sensing distance, NPN normally open output, and a 5m PVC cable. It's rated for flush mounting so you don't lose detection range when embedded in metal.

Shielded construction allows flush mounting in metal. NPN output is current-sinking; the normally open action means the output is off until a ferrous object enters the 2mm window. The M12 threaded barrel is short-body (shorter than standard), which helps in tight spaces. The 5m PVC cable gives you reach to the controller without a junction box. PVC is fine for dry, non-oily environments; if cutting fluid or coolant is present, consider a PUR cable variant.

Frequently asked questions

What are the key ratings of this sensor?

Shielded M12 housing, 2mm sensing distance, NPN normally open output, 5m PVC cable, short body.

MPN
E2B-M12KS02-WP-C1 5M
