Omron E2B, Proximity sensor, 12 mm diameter, 8 mm sensing distance, PNP NO, Unshielded, M12 connector, long body, brass.
| Parameter | Value |
|---|---|
| Sensing distance | 8mm sensing distance |
| Parameter | Value |
|---|---|
| Operation mode | Normally open |
| Parameter | Value |
|---|---|
| Shield | Unshielded |
| Weight | 0.00 kgs |
| Housing size | 12 mm diameter |
| Barrel length | Long body |
| Connection type | M12 connector |
| Power source and output | PNP |
| Housing shape and material | Cylindrical, metric thread, brass |
The Omron E2B-M12LN08-M1-B1 is a cylindrical inductive proximity switch in the standard 12 mm diameter. Rated for 8 mm sensing distance, unshielded, with a PNP normally-open output and an M12 quick-disconnect connector. The brass housing and long barrel body suit industrial mounting on brackets or stands.
Unshielded construction requires clearance from surrounding metal. The cylindrical brass housing has a 12 mm diameter and M12 connector.
Yes, the PNP normally-open output provides a positive signal (sourcing) that interfaces directly with most 24V DC PLC sinking inputs.
Alternative models and sibling configurations in the same Omron series. For obsolete or discontinued parts, these models can serve as compatible replacements or functional alternatives for plant maintenance.
