The E2E-X2C2L8 2M: M8 shielded inductive sensor, NPN normally-closed output. Senses ferrous targets up to 2 mm. Stainless steel body rated IP67 and IP69K for wet environments. Supply 10-30 VDC. Response frequency 1.5 kHz is adequate for moderate-speed sensing. Three-wire NPN-NC: brown supply, blue ground, black output. Normally-closed means output sinks when target is absent. Cable leads are molded — no connector to swap. Mount through M8 threaded hole; shielded design limits sensing to the face only, so flush mounting in metal is allowed.
Omron E2E-X2C2L8 2M Inductive Sensor, Shielded, NPN-NC, M8
MPNE2E-X2C2L8 2M
Omron E2E-X2C2L8 2M, an inductive proximity sensor from the E2E NEXT series. Shielded M8 threaded cylinder, NPN-NC 3-wire output, 2 mm sensing distance, cable leads.
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | E2E NEXT |
| Parameter | Value |
|---|---|
| Sensing distance | 0.079" (2mm) |
| Shielding | Shielded |
| Parameter | Value |
|---|---|
| Operating temperature range | -25°C ~ 70°C |
| Parameter | Value |
|---|---|
| Case | Cylinder, Threaded - M8 |
| Indicator | LED |
| Output signal | NPN-NC, 3-Wire |
| Sensor type | Inductive |
| Material - body | Stainless Steel |
| Supply voltage | 10V ~ 30V |
| Termination style | Cable Leads |
| IP rating | IP67, IP69K |
| Response frequency | 1.5kHz |
Product details
Frequently asked questions
What is E2E-X2C2L8 2M's listed case?
Cylindrical M8 threaded, part of the E2E NEXT series.
What is the series designation?
E2E NEXT series.
What is the sensing distance?
2 mm shielded.
MPN
E2E-X2C2L8 2M
