Omron E2E-X2D1-M3G — Proximity Sensors

Omron E2E-X2D1-M3G Shielded Proximity Switch, 2mm

MPNE2E-X2D1-M3G

Omron E2E-X2D1-M3G, Shielded Inductive Proximity Switch, 2mm range, M8 4-pin, DC 2-wire NO.

$66.80Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

E2E-X2D1-M3G — Sensing
ParameterValue
Sensing distance2 mm range
ShieldingShielded
E2E-X2D1-M3G — Output
ParameterValue
Operation modeNormally open
E2E-X2D1-M3G — Other specifications
ParameterValue
Weight0.45 kgs
PolarityPolarity
Body lengthStandard length
Connection methodM8 4-pin connector (IEC arrangement)
Output configurationDC 2-wire
Oscillation frequencyStandard freq.

Product details

The Omron E2E-X2D1-M3G is a shielded inductive proximity switch with a 2 mm sensing distance, terminated to an M8 4-pin connector per IEC arrangement. Its output is DC 2-wire, normally open. Polarity matters on this type — reverse connection will destroy the sensor. It is rated for current production, so no last-time-buy clock is running.

The shielded construction allows flush mounting in metal, eliminating the need for a non-ferrous standoff zone. Verify the M8 connector pinout matches the cable assembly on hand; the 4-pin IEC arrangement is standard but not universal.

Frequently asked questions

Will the E2E-X2D1-M3G drop into a panel wired for the E2C-X1R5AH?

No — the E2C-X1R5AH uses a pre-wired 3 m cable, while the E2E-X2D1-M3G uses an M8 4-pin connector. Sensing distances also differ (1.5 mm vs 2 mm). Rewiring is required.

MPN
E2E-X2D1-M3G
