E2E-X4C2L8-M1: Shielded housing permits flush mounting. M8 thread fits standard brackets. For wiring: brown to positive supply, blue to 0V, black to load. NPN-NC output sinks current when no target; configure PLC input sourcing.
Omron E2E-X4C2L8-M1 Inductive Sensor, M8 Shielded, NPN-NC, 4
MPNE2E-X4C2L8-M1
Omron E2E NEXT, Inductive Proximity Sensor, M8 Cylinder Threaded, Shielded, NPN-NC 3-Wire, 4mm Sensing Distance, 10-30V, IP67/IP69K, 700Hz.
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | E2E NEXT |
| Parameter | Value |
|---|---|
| Sensing distance | 0.157" (4mm) |
| Shielding | Shielded |
| Parameter | Value |
|---|---|
| Operating temperature range | -25°C ~ 60°C |
| Parameter | Value |
|---|---|
| Case | Cylinder, Threaded - M8 |
| Indicator | LED |
| Output signal | NPN-NC, 3-Wire |
| Sensor type | Inductive |
| Material - body | Nickel-Plated Brass |
| Supply voltage | 10V ~ 30V |
| Termination style | Connector |
| IP rating | IP67, IP69K |
| Response frequency | 700Hz |
Product details
Frequently asked questions
What is the case/body style of this sensor?
M8 threaded cylindrical body with nickel-plated brass construction.
What series does this sensor belong to?
It is part of the E2E NEXT series.
MPN
E2E-X4C2L8-M1
