Omron E2E-X5B1DL18-M1 — Proximity Sensors

Omron E2E-X5B1DL18-M1 Inductive Prox, M12, 5mm, PNP NO

MPNE2E-X5B1DL18-M1

Omron E2E NEXT Series, inductive cylindrical proximity sensor, M18 threaded shielded, PNP NO, M12 connector, 5 mm sensing, 10-30 VDC, 200 mA, IP67/IP69K, 75 mm body.

$129.69 – $152.36Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

E2E-X5B1DL18-M1 — Identification
ParameterValue
SeriesE2E NEXT
E2E-X5B1DL18-M1 — Sensing
ParameterValue
Sensing distance, max. (alt.)5 mm
Sensing methodInductive
Sensing-face shieldingShielded
E2E-X5B1DL18-M1 — Electrical
ParameterValue
Supply voltageNot Rated ; 10-30V DC
AC supply voltage ratingNot Rated
DC supply voltage rating10-30V DC
Number of wires3
Electrical connectionM12
Electrical installation typeDirect Connector
E2E-X5B1DL18-M1 — Output
ParameterValue
Output circuit contact formNO
Output circuit typePNP
Includes indicator lightsIndicator Lights Included
Output circuitPNP
E2E-X5B1DL18-M1 — Mechanical
ParameterValue
Body styleCylindrical
Overall height75 mm
Body materialBrass
E2E-X5B1DL18-M1 — Environmental
ParameterValue
Operating temperature, max. (alt.)185 °F
Operating temperature, min. (alt.)-40 °F
IP ratingIP67; IP69K
E2E-X5B1DL18-M1 — Approvals
ParameterValue
Standards / certificationsCE; CSA; CSA C22.2; UL 60947-5-2 4; UL 60947-5-2-14

Product details

What this sensor brings to the line

The E2E-X5B1DL18-M1 is a shielded M18 inductive proximity sensor with a flush 5 mm sensing range, PNP normally-open output, and an M12 quick-disconnect connector. Built into the E2E NEXT series, it runs on 10-30 VDC, sinks up to 200 mA, and carries IP67 and IP69K ratings — meaning it can handle high-pressure, high-temperature washdown cycles common in food, beverage, and pharmaceutical lines. The brass barrel is nickel-plated, and the operating range of -40°F to 185°F covers both freezer tunnels and hot CIP rinse zones.

Key detail: body length vs the M12 peer

Body length is 75 mm vs the 53 mm of the E2E-X5B1D18-M1. Same wiring and sensing specs.

The E2E-X5B1DL18-M1 is CE-marked, CSA certified, and UL listed under UL 60947-5-2. Incoming inspection documentation (certificate of conformance, RoHS/REACH declarations) can be provided with the RFQ package. Multi-source compliance records are maintained on file for each production lot.

Frequently asked questions

What is the difference between E2E-X5B1DL18-M1 and E2E-X5B1D18-M1?

Both are M18 shielded, PNP NO, M12 connector, 5 mm sensing, 10-30 VDC, 200 mA. The only difference is body length: this one is 75 mm, the E2E-X5B1D18-M1 is 53 mm. Electrical and mechanical interfaces are identical.

What compliance documentation is available for this sensor?

It is CE marked, CSA certified, and UL listed under UL 60947-5-2. Certificates of conformance and RoHS/REACH declarations are provided with each RFQ shipment.

MPN
E2E-X5B1DL18-M1
