The Omron E2E-X7D1-M1 is a shielded inductive proximity sensor from the E2E series, housed in an M18 threaded nickel-plated brass cylinder. It switches at up to 500 Hz with a 7 mm sensing distance, suited for metal target detection in automated machinery. Rated for 10 to 30 VDC supply and outputting an NPN normally-open signal, the 2-wire connection simplifies wiring. The IP67 rating means it withstands washdown and coolant exposure on the factory floor.
Omron E2E-X7D1-M1 Inductive Sensor, M18, 7mm, NPN-NO
MPNE2E-X7D1-M1
Omron E2E series, Inductive proximity sensor, M18 threaded, shielded, NPN-NO 2-wire, 7mm sensing distance, 10-30 VDC, IP67.
$48.26Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | E2E |
| Parameter | Value |
|---|---|
| Sensing distance | 0.276" (7mm) |
| Shielding | Shielded |
| Parameter | Value |
|---|---|
| Operating temperature range | -25°C ~ 70°C |
| Parameter | Value |
|---|---|
| Case | Cylinder, Threaded - M18 |
| Indicator | LED |
| Output signal | NPN-NO, 2-Wire |
| Sensor type | Inductive |
| Material - body | Nickel-Plated Brass |
| Supply voltage | 10V ~ 30V |
| Termination style | Connector |
| IP rating | IP67 |
| Response frequency | 500Hz |
Product details
MPN
E2E-X7D1-M1
