Omron E2E-X8MB1T12-M1 — Proximity Sensors

Omron E2E-X8MB1T12-M1 M12 PNP Proximity, 8mm

MPNE2E-X8MB1T12-M1

Omron E2E NEXT, inductive proximity sensor, E2E-X8MB1T12-M1, M12, unshielded, 8 mm, PNP NO, M12 connector, IO-Link.

$21.97Ref. price · indicative, final on quote

Add to RFQ

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

E2E-X8MB1T12-M1 — Sensing
Parameter	Value
Sensing distance	8 mm range
Shielding	Unshielded

E2E-X8MB1T12-M1 — Output
Parameter	Value
Operation mode	Normally open

E2E-X8MB1T12-M1 — Other specifications
Parameter	Value
Weight	0.45 kgs
Body length	Standard length
Body diameter	M12 size
Connection method	M12 connector
IO-Link baud rate	IO-Link 230.4 kbps
Output configuration	DC 3-wire, PNP
Oscillation frequency	Standard freq.

Product details

The Omron E2E-X8MB1T12-M1 is an E2E NEXT inductive proximity sensor with an 8 mm sensing range, PNP normally-open output, and IO-Link communication at 230.4 kbps. M12 housing, unshielded, fitted with a standard M12 connector for quick disconnection and field replacement. Rated for DC 3-wire PNP output, normally open — direct wiring to a sinking PLC input.

Integration

Standard body length fits M12 mounting brackets; unshielded design requires clearance from surrounding metal to avoid sensing dead zones. IO-Link bus allows remote parameter adjustment and diagnostic feedback — useful for condition monitoring without pulling a panel.

Frequently asked questions

Will the E2E-X8MB1T12-M1 drop into a panel that was specified around E2KQ-X10ME1 without rewiring?

No — the E2KQ-X10ME1 is a capacitive sensor with NPN output; the E2E-X8MB1T12-M1 is inductive with PNP output. Different technology and output logic require new wiring and PLC input reconfiguration.
