The Omron E2EX10Y1 (model E2E-X10Y1) is an AC inductive proximity switch for detecting ferrous metal targets. It offers a nominal sensing distance of 10 mm with a usable set range of 0 to 8 mm. Rated for 24 to 240 V AC supply, it switches up to 100 mA with a maximum leakage current of 1.7 mA. The normally open or normally close output is selectable depending on wiring. Housing is nickel-plated brass with IP67 sealing, pre-wired with a 2-meter oil-resistant PVC cable. Ambient temperature range spans -40 to 85 °C.
Omron E2EX10Y1 Proximity Switch, 10mm, 24-240VAC
MPNE2EX10Y1
Omron E2E-X10Y1 (E2EX10Y1) Proximity Switch Sensor, Inductive, 10 mm sensing, 24 … 240 V AC, IP67, Pre-wired 2 m.
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Type | Proximity Switch sensor |
Sensing
| Parameter | Value |
|---|---|
| Sensing distance | 10 mm |
Output
| Parameter | Value |
|---|---|
| Operation mode | Normally Open, Normally Close |
Mechanical
| Parameter | Value |
|---|---|
| Housing material | Nickel-plated brass |
Product details
Frequently asked questions
When sourcing E2EX10Y1, what is the closest functional second-source like E3Z-LL61?
The E3Z-LL61 is a photoelectric sensor that operates on 12-24 VDC and uses light reflection, not induction. It is not a direct functional replacement for the E2EX10Y1 because of different sensing principles and power supply requirements.
Will E2EX10Y1 drop into a panel that was specified around E3Z-LL61 without rewiring?
No. The E3Z-LL61 runs on 12-24 VDC and is photoelectric; the E2EX10Y1 runs on 24-240 V AC and is inductive. Panel wiring, power supply, and control logic would all need to change.
MPN
E2EX10Y1
