It outputs NPN-NO through a 3-wire cable lead and detects ferrous targets at 2 mm. The 2 mm sensing distance is the working range for a mild steel target; the shielded construction allows flush mounting in metal panels without derating the sensing gap. For non-flush applications the same sensor works, but the effective range remains 2 mm. Supply voltage spans 10 to 30 VDC, with a 1.5 kHz response frequency that suits moderate-speed part detection on conveyors or machine tools. The NPN-NO output pulls low when a target enters the sensing field, sinking current from the load. IP67 ingress protection and a -25 to 70°C operating temperature range cover washdown zones and unheated plant floors. The cable leads (2 m, factory-fitted) save a panel-side connector step for fixed installations.
Omron E2FQ-X2E1 Inductive Sensor, NPN-NO, 2mm, IP67
MPNE2FQ-X2E1
Omron E2F series, Inductive proximity sensor, Cylinder M12, Shielded, NPN-NO 3-Wire, 2mm sensing, 10-30V, IP67.
$118.11Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | E2F |
| Parameter | Value |
|---|---|
| Sensing distance | 0.079" (2mm) |
| Shielding | Shielded |
| Parameter | Value |
|---|---|
| Operating temperature range | -25°C ~ 70°C |
| Parameter | Value |
|---|---|
| Case | Cylinder, Threaded - M12 |
| Indicator | LED |
| Output signal | NPN-NO, 3-Wire |
| Sensor type | Inductive |
| Material - body | Plastic |
| Supply voltage | 10V ~ 30V |
| Termination style | Cable Leads |
| IP rating | IP67 |
| Response frequency | 1.5kHz |
Product details
Frequently asked questions
What is the housing shape and size?
The sensor is housed in a threaded M12 cylindrical plastic body, shielded. The threads allow mounting through a 12 mm hole with a lock nut.
What is the sensing distance and output type?
It senses ferrous metals at 2 mm and provides an NPN normally-open output via a 3-wire cable.
MPN
E2FQ-X2E1
