The Omron E30SDR-A is a CP1E CPU Unit with 30 I/O points — 18 DC inputs and 12 relay outputs — powered by 100-240 VAC (85-264 VAC operating range). It carries a renewal type designation, meaning it directly replaces earlier CP1E CPU units without requiring wiring or program changes. CPU model is CP1E; dimensions are 7.8 cm x 13 cm x 9 cm.
Omron E30SDR-A CP1E CPU, 30 I/O, Relay Output, AC
MPNE30SDR-A
Omron CP1E CPU Unit Hardware, E30SDR-A, 30 I/O (18 DC inputs, 12 relay outputs), AC power supply.
$300.00Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Mechanical
| Parameter | Value |
|---|---|
| Weight | 0.67 Kg |
Other specifications
| Parameter | Value |
|---|---|
| CPU model | CP1E |
| Unit type | S = Renewal type |
| Input type | D = DC inputs |
| Output signal | R = Relays output |
| I (O capacity) | 30 = 30 I/O points (18 inputs, 12 outputs) |
| Power supply | A = AC power supply |
| Product type | CP1E CPU Unit Hardware |
| Supply voltage | 100 to 240 VAC 50/60 Hz |
| Operating voltage range | 85 to 264 VAC |
| Dimensions (L × w × h) | 7.8 cm x 13 cm x 9 cm |
Product details
MPN
E30SDR-A
