The E3FA-DP122M: M18 threaded diffuse sensor with PNP output and a 300 mm sensing distance. The IP69K rating means it takes the caustic CIP washdowns common in a brewery. Response time sits at 0.5 msec, fast enough for high-speed canning lines. Red LED emission, selectable light-on/dark-on switching, and indicator lights make commissioning straightforward. Reverse polarity and short circuit protection on the output and power supply reduce field failures.
Lifecycle and sourcing
Current active lifecycle stage; sourced to order through our distribution channel. Send an RFQ for your required quantity.
Mounting and wiring notes
Mount through an 18 mm hole; the right-angle face orients the lens for side-looking detection. The plastic body withstands washdown but avoid overtightening the mounting nut. The 2 m prewired cable has bare ends — terminate in a junction box rated for the same environmental seal. Supply 10–30 V DC, output is PNP sourcing, max load 100 mA. Select light-on or dark-on via the single wire (typically white); indicator lights give immediate feedback during setup.
