Controls integrator's fit note
The E3FB-DP112M is an M18 threaded diffuse photoelectric sensor with a right-angle face and 2-meter prewired cable. Diffuse sensing at 100 mm maximum, PNP output, 10-30 VDC supply. The body is brass; ratings include IP67 and IP69K, so this sensor survives daily hot-caustic CIP washing in food lines. The prewired cable avoids a connector that could trap moisture, but also means you commit to a 2 m lead length when replacing a failed unit.
Mounting and wiring notes
M18 brass body with right-angle face. Prewired 2 m bare-wire cable, 10-30 VDC supply, 100 mA load max, selectable light-on/dark-on, 0.5 ms response.
