Omron E3S-AT61-L, through-beam photoelectric sensor, NPN output, 7 m range, IP67, M12 connector, pulse modulated red LED.
| Parameter | Value |
|---|---|
| IP rating | IP67 |
| Output signal | NPN |
| Light_source | Pulse modulated red LED (700 nm) |
| Product type | Photoelectric Sensor |
| Sensitivity_n | 2 |
| Operation_mode | Light-ON/Dark-ON operation, switch selectable |
| Supply voltage | 30 |
| Connection_method | M12 Connector, 4 Pin |
| Method_of_detection | Through-beam |
| Switching current | 0.04 |
| Sensing distance max | 7000 |
| Operating temperature high | -25 … 55°C |
The E3S-AT61-L: Sensitivity adjustment is a 2-turn knurled pot with clutch – set it once, it stays. No short-circuit protection on the output, so fuse the load side accordingly. The M12 connector mates with standard 4-pin cordsets; pin 4 is the load output (NPN sinking).
The order code E3S-AT61-L corresponds to E3SAT61L. Same sensor, different label format. A BOM line written around E3SAT61L drops in without rewiring.
IP67, rated for dust-tight and temporary immersion.
Yes, it is the identical sensor. Same mounting, same M12 pinout, same electrical ratings.
