What it is and what it delivers
The E3SDBP21TOMS is a PNP retro-reflective photoelectric sensor from Omron's E3S-DB family, rated for 4.5 m sensing distance with a 500 µs response time. Output is PNP, switching Light-ON or Dark-ON, carrying 100 mA load directly into a PLC input. Powered from 10–30 VDC and terminated with an M12 4-pin connector. The housing seals to IP67 and IP69K, so it handles high-pressure washdown in food, beverage, or heavy-wash environments. Operating range from -25 °C to 60 °C covers both cold storage and warm industrial zones. Physical footprint is 15.8 mm wide by 48.5 mm tall by 40.5 mm deep — slim enough for tight DIN-rail or bracket layouts.
How it compares to E3FARP21F2OMS
The closest peer in function is the E3FARP21F2OMS (E3FA series). Both are PNP retro-reflective with M12 connector, IP67/IP69K, 500 µs response, and 100 mA load. The key deltas are sensing distance and blanking zone: this E3S-DB sensor reaches 4.5 m versus 4 m on the E3FA, and starts sensing at 0 mm instead of 100 mm. That zero blind zone lets you mount the sensor right against the target edge — useful on a short conveyor or when the reflector is tight to the frame. The E3S-DB body is narrower at 15.8 mm versus 16.6 mm for the E3FA. If the existing panel cutout or bracket was sized for 16.6 mm, this sensor will fit with a bit of slop; if the bracket has a fixed 16.6 mm pocket, a shim or adapter clip may be needed. The 4.5 m range does give you headroom to pull the sensor back if the min distance issue arises. No rewiring required — both use the same M12 4-pin pinout and PNP logic — but the E3S-DB series has its own mounting accessories. Confirm bracket or bracket hole pattern if swapping between series.
