Omron E5AN-HSS3BFMD-500 AC/DC24
MPNE5AN-HSS3BFMD-500 AC/DC24
Obsolete
E5AN-H|Universal digital process controllers
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Input type | Thermocouple, RTD, Linear |
| Supply voltage | 24 VAC/VDC |
| IP rating | IP66 |
| Protocol | Serial, Modbus, PROFIBUS (via gateway), SYSWAY |
| Communications | USB (E58-CIFQ1), Option Units RS-232C (E53-EN01), RS-422 (E53-EN02), RS-485 (E53-EN03) |
| Operating temperature | > 700°C |
| Dimensions | 1/4 DIN (96x96 mm) |
| Alarms | 3 Relays |
| Output | 2 alarms or more, Alarm output relay, Remote setpoint, Event IP (1 or 2), Transfer output |
| Display | Triple line |
| Event inputs | 2 |
| Control method | ON/OFF-control, 2-PID control |
All specifications
| Parameter | Value |
|---|---|
| Ramp (Soak cycle) | 4 Simple Patterns |
| Transfer output | Yes |
| Control function | Heat & cool |
| Control output 2 | Solid State Relay |
| Second set point | Yes |
| Main control output | Solid State Relay |
| Input sampling period | 60 ms |
| Remote set point input | 1 |
MPN
E5AN-HSS3BFMD-500 AC/DC24
