The Omron G3PA-420B-VD-2 DC12-24 is a solid state relay from the G32A-D series, switching three-phase AC loads via a 12 to 24V DC control input. The input is rated for 20 A, and the relay carries CSA and UR certifications. Mounts with screw terminals; body dimensions are 3.93 in deep, 0.78 in wide, and 3.93 in high.
Omron G3PA-420B-VD-2 DC12-24 Solid State Relay, 20 A, 12-24
MPNG3PA-420B-VD-2 DC12-24
Omron G3PA-420B-VD-2 DC12-24, Solid State Relay, Series G32A-D, 20 A Input, 12-24 VDC, Screw Connection, Three-Phase AC Output, CSA, UR.
$101.60 – $288.85Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | G32A-D |
| Standards | CSA; UR |
| Body depth | 3.93 in |
| Body width | 0.78 in |
| Body height | 3.93 in |
| Current type | AC |
| Input current | 20 A |
| Input voltage | 12 to 24V DC |
| Electrical phase | Three |
| Electrical connection type | Screw |
Product details
Frequently asked questions
What are the key ratings of the G3PA-420B-VD-2 DC12-24?
The relay has a 20 A input rating, accepts a 12 to 24V DC control voltage, and switches three-phase AC loads. It is certified to CSA and UR standards.
What series does the G3PA-420B-VD-2 DC12-24 belong to?
It is part of the G32A-D series of solid state relays.
What certifications does the G3PA-420B-VD-2 DC12-24 carry?
It carries CSA and UR certifications.
MPN
G3PA-420B-VD-2 DC12-24
