Omron G7SA5A1B

Omron G7SA5A1B Safety Relay, 6 Poles, 5NO+2NC, 24VDC Coil

MPN G7SA5A1B

Omron G7SA-5A1B safety relay, 6-pole, 5PST-NO + DPST-NC, 24 VDC coil, flux-tight sealed, standard type.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

G7SA5A1B specifications
ParameterValue
Product typeSafety Relay
Poles6 poles
Weight0.025 Kg

Product details

Omron G7SA5A1B is a 6-pole safety relay with 5 normally-open (5PST-NO) and 2 normally-closed (DPST-NC) contacts, 24 VDC coil, flux-tight sealed. Standard type — no forced-guided contacts, so it fits basic safety circuits where the relay itself is not the sole monitoring element. The flux-tight seal means the housing withstands wave-solder flux ingress during PCB assembly; fine for automated production but not rated for washdown.

Contact Configuration & Fit

Five NO poles handle the safety output channels (e.g., dual-channel monitoring with feedback loop); two NC poles serve as auxiliary status contacts or a second safety path. The 6-pole count is high for a compact safety relay — typical 3- or 4-pole relays would need two units to match this contact density.
