Omron G9SA-EX301

Omron G9SA-EX301 Safety Relay Extension, 24V, 2 Inputs, SPST

MPN G9SA-EX301

Omron G9SA series, safety relay extension module, G9SA-EX301, 24V AC/DC, 2 inputs, SPST-NC contact, 5 A rated, DIN-rail mount, IP20.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

G9SA-EX301 key specifications
ParameterValue
Terminal typeScrew
Input voltage24 V
Current5 A
Power2 VA
Frequency50/60 Hz
Contact formSPST-NC
IP ratingIP20
MountingDIN-Rail &amp, Surface
Terminal count8
Response time10 msec
Temp operating max131 °F
Temp operating min-13 °F

All specifications

G9SA-EX301 additional specifications
ParameterValue
Depth110.998 mm
Width17.526 mm
Height75.946 mm
Electrical life cycles100000
Mechanical life cycles5000000
I/O channels2
Channels2
Timing functionAdjustable

Product details

The Omron G9SA-EX301 is a safety relay extension module that adds a second safety channel to a G9SA-series safety relay base unit. It accepts two input signals and switches one normally-open main contact plus one normally-closed auxiliary contact, both rated 5 A. The 17.5 mm wide DIN-rail housing keeps panel fill factor tight — it's the same width as a standard miniature circuit breaker, so it slots into a crowded enclosure without re-laying the backplane.

The 5 A contact rating covers most pilot-duty loads — contactor coils, solenoid valves, indicator lamps — but not direct motor switching. The SPST-NC auxiliary is a feedback contact that the base safety relay monitors; if the extension loses its seal, the base opens both channels. Response time is 10 msec, which is typical for electromechanical safety relays and fast enough for Category 3 / PL d circuits per EN 954-1. The adjustable timing function means you can set off-delay on the extension's output, useful for staggered stop sequences on a conveyor or press guard.

This module is the expansion slice — it cannot run standalone. It mates to a G9SA base unit (like the G9SA-301 or G9SA-321) via the internal bus, extending the number of monitored input channels and output contacts. The IP20 finger-safe housing means it's intended for a locked control panel, not a washdown zone. The LED indicator shows input status, which helps during commissioning when you're chasing a mis-wired e-stop string.
