G9SAEX301
Omron G9SAEX301
MPNG9SAEX301
OMRON Safety Relay Extension Module: DIN-Rail Relay Mounting, 8 Pins/Terminals, 24V AC/DC, 2 Inputs
$128.55 – $222.50Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Delay type | Adjustable |
| Electrical connection type | Screw |
| Input voltage | 24V AC/DC |
| Power consumption | 2 VA |
| Frequency | 50/60 Hz |
| Contact form | SPST-NC |
| I/O channels | 2 |
| IP rating | IP20 |
| Relay mounting style | DIN-Rail & Surface |
| Number of terminals | 8 |
| Response time | 10 msec |
| Maximum operating temperature | 131 °F |
All specifications+15 ▾
| Parameter | Value |
|---|---|
| Minimum operating temperature | -13 °F |
| Body depth | 4.37 in |
| Body width | 0.69 in |
| Body height | 2.99 in |
| Electrical operating durability | 100,000 |
| Mechanical operating durability | 5,000,000 |
| Standards | CSA Certified; UL Listed |
| Brand | OMRON |
| For use with | G9SA Series Safety Relays |
| Status indicator | LED Indicator |
| Contact rating | 5 A @ 250V |
| Safety reliability data | EN574 (-TH301); EN60204-1; EN954-1 |
| Environmental protection | Finger-Safe |
| Number of input channels | 2 |
| Output switch configuration | (1) NC Aux(1) NO Main |
MPN
G9SAEX301
