Omron SmartSlice Output Module, GRT1-OD4, 4 Solid State Outputs, 24VDC.
| Parameter | Value |
|---|---|
| Series | SmartSlice |
| Type | Output Module |
| Compatible with | CJ, CS, NJ Series |
| Parameter | Value |
|---|---|
| Outputs and output technology | 4 - Solid State |
| Parameter | Value |
|---|---|
| Operating temperature range | -10°C~55°C |
| Parameter | Value |
|---|---|
| Mounting type | DIN Rail |
| Termination style | Screw Terminal |
| Parameter | Value |
|---|---|
| Weight | 0.168 lb (76.2 g) |
| Supply voltage | 24VDC |
| IP rating | IP20 |
The Omron GRT1-OD4 is a SmartSlice output module delivering four solid-state outputs from a 24 VDC DIN-rail slice, wired via screw terminals. Rated for CJ, CS, and NJ series backplanes, it communicates over the SmartSlice bus — not a standalone device. IP20 and -10 to 55°C operating range keep it inside the panel, away from dust and moisture.
It is an Output Module in the SmartSlice series with 4 solid-state outputs, 24VDC supply, DIN-rail mount, screw terminals, IP20, and -10°C to 55°C operating temperature.
