Omron GRT1-TS2PK — PLCs (Programmable Logic Controllers)

Omron GRT1-TS2PK SmartSlice 2 Analog Input Module, Obsolete

MPNGRT1-TS2PK
Obsolete

Omron SmartSlice GRT1-TS2PK, 2 analog input module, 24VDC, screw terminal, DIN rail, IP20.

$847.55Ref. price · indicative, final on quote
Omron GRT1-TS2PK datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

GRT1-TS2PK — Identification
ParameterValue
SeriesSmartSlice
GRT1-TS2PK — I/O
ParameterValue
Inputs (count and type)2 - Analog
GRT1-TS2PK — Electrical
ParameterValue
Supply voltage24VDC
GRT1-TS2PK — Environmental
ParameterValue
Operating temperature range-10°C ~ 55°C
GRT1-TS2PK — Mechanical
ParameterValue
Mounting typeDIN Rail
Weight0.19 lb (86.18 g)
Termination styleScrew Terminal
GRT1-TS2PK — Approvals
ParameterValue
Approvals / certificationsCE, cULus, Lloyd
GRT1-TS2PK — Other specifications
ParameterValue
TypeInput Module
IP ratingIP20

Product details

GRT1-TS2PK – 2 Analog Input SmartSlice Module, Now Obsolete

The Omron GRT1-TS2PK is a 2-channel analog input module in the SmartSlice I/O family, designed for DIN-rail mounting and wired via screw terminals. It accepts two analog signals at 24 VDC supply, with approvals from CE, cULus, and Lloyd.

If You Can't Find the PK, Grab the P – The GRT1-TS2P

Don't grab the GRT1-ID4 digital input module if you need analog – that's a 4-point digital unit with different wiring.

Slots into any SmartSlice backplane alongside CJ, CS, and NJ series controllers. Termination is screw clamp – strip length should follow usual SmartSlice practice. Operating temperature -10 to 55 °C, IP20 for dry indoor cabinets. Approvals listed: CE, cULus, Lloyd (for marine/offshore applications). No RoHS or REACH statement in the spec record – verify with seller if needed for your compliance gate.

Frequently asked questions

When sourcing GRT1-TS2PK, what's the closest functional second-source?

The GRT1-TS2P is an identical functional match with the same specs (2 analog inputs, 24VDC, screw terminal, approvals). It will drop into the same panel without changes.

What is GRT1-TS2PK's listed type on this component line?

It is an Input Module – 2 analog inputs.

What is GRT1-TS2PK's series?

SmartSlice.

Will GRT1-TS2PK drop into a panel that was specified around GRT1-TS2P without rewiring?

Yes. The GRT1-TS2P shares the exact same specifications: 2 analog inputs, 24VDC, screw terminals, DIN mount, same approvals and dimensions. It is a direct functional spare.

What compliance documentation does this brand provide for GRT1-TS2PK (RoHS, REACH, UL, IEC)?

The module carries CE, cULus, and Lloyd (marine) approvals. No RoHS or REACH status is in the available spec data.

MPN
GRT1-TS2PK
