The Omron H3CR-HRL AC200-240 M is an off-delay timer relay from the H3CR-H series, socketable with an 11-pin octal base. It provides a single timing function: off-delay, adjustable via a front-panel hand dial from 0.05 minutes to 12 minutes. The DPDT (2 Form C) output contacts are rated 5 A at 250 VAC, suitable for switching control loads like contactor coils, small motors, or indicator circuits in panel applications.
Supply and timing
Supply voltage is 200 to 240 VAC, with timing initiated by applying input voltage. The off-delay function means the relay energizes immediately when power is applied, then begins its delay when power is removed — the contacts transfer back to the de-energized state after the set delay elapses. This is the standard function for sequenced shutdown or post-run cooling in conveyor, pump, or fan applications. The 0.05 min to 12 min adjustment range covers short purge cycles through extended post-lubrication delays. Adjustment is by hand dial on the timer face, no tools needed for field changes.
Socketable with an 11-pin octal base — mates to standard industry octal relay sockets (e.g. Omron PYF-11A or equivalent). The plug-in form factor means a failed timer can be swapped in seconds without disturbing panel wiring. Termination style is plug-in, 11 pin (octal).
Listed as active in production. This is a mature, widely stocked series — the H3CR-H platform has been a standard in industrial timing for years.
