The Omron H5CN-XAN DC12-48 is an on-delay timer relay from the H5CN series, switching a SPDT (1 Form C) contact rated 3A at 250VAC. It operates on a 12 to 48 VDC supply and covers delay times from 0.001 second up to 9.999 seconds, set via up/down digit keys. The timing is initiated by applying input voltage, and the relay mounts into an 8-pin octal socket — common in control panels where a compact, programmable delay is needed for sequencing or staging events.
Omron H5CN-XAN DC12-48 On-Delay Timer, SPDT, 0.001-9.999s
MPNH5CN-XAN DC12-48
Active
Omron H5CN series, On-Delay timer relay, SPDT (1 Form C), 3A @ 250VAC, 12-48VDC supply, 0.001-9.999s range, socketable octal base.
$281.69 – $346.33Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | H5CN |
| Parameter | Value |
|---|---|
| Function | On-Delay |
| Parameter | Value |
|---|---|
| Delay time range | 0.001 Sec ~ 9.999 Sec |
| Timing adjustment method | Up/Down Digit Keys |
| Timing initiate method | Input Voltage |
| Parameter | Value |
|---|---|
| Supply voltage | 12 ~ 48VDC |
| Parameter | Value |
|---|---|
| Contact rating @ voltage | 3A @ 250VAC |
| Contact circuit (Form) | SPDT (1 Form C) |
| Relay type | Mechanical Relay |
| Parameter | Value |
|---|---|
| Mounting type | Socketable |
| Termination style | Plug In, 8 Pin (Octal) |
Product details
Frequently asked questions
Where can I buy the H5CN-XAN DC12-48?
This part is sourced and quoted to order against an RFQ through independent distribution; availability and current pricing are confirmed at quote time.
What is the timing range and adjustment method for the H5CN-XAN DC12-48?
The delay time is adjustable from 0.001 second to 9.999 seconds using up/down digit keys, with timing initiated by applying input voltage.
