Omron H5CN-XBN DC12-48

Omron H5CN-XBN DC12-48 On-Delay Timer, SPDT, 0.001-99.99s

MPN H5CN-XBN DC12-48
Active

Omron H5CN series, On-Delay timer relay, SPDT (1 Form C), 3A @ 250VAC, 12-48VDC supply, 0.001-99.99s range, octal plug-in, socketable.

$289.12 – $384.81 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

H5CN-XBN DC12-48 specifications
ParameterValue
SeriesH5CN
TypeMechanical Relay
Supply voltage12 to 48VDC
MountingSocket
PackageBulk
Delay time0.001 Sec to 9.999 Sec
Timing initiate methodInput Voltage
Timing adjustment methodUp/Down Digit Keys

Product details

The Omron H5CN-XBN DC12-48 is an on-delay timer relay from the H5CN series, switching a SPDT (1 Form C) contact rated at 3A @ 250VAC. It accepts a 12-48VDC supply and covers a delay range from 0.001 to 99.99 seconds, set via up/down digit keys. This is a socketable, mechanical relay with an octal (8-pin) plug-in termination — mounts into a standard 8-pin octal relay socket, which is a common panel layout. The timing initiate method is input voltage: applying the DC supply starts the delay cycle.

The 3A contact rating at 250VAC covers typical control-circuit loads — pilot lights, contactor coils, small solenoid valves. The 0.001-99.99s range with digital keypad adjustment gives precise repeatability for timing sequences like conveyor staging or pump alternation.

MPN
H5CN-XBN DC12-48
