Omron H5CN-XBNM DC24 — Electronic Timers & Counters

Omron H5CN-XBNM DC24 Time Delay Relay, On-Delay 0.001-99.99s

MPNH5CN-XBNM DC24
Active

Omron H5CN series, On-Delay time delay relay, SPDT (1 Form C), 0.001 ~ 99.99 Sec, 12 ~ 48 VDC supply, 3A @ 250VAC, Octal 11-pin plug-in, Up/Down digit key adjustment.

$323.36 – $384.81Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

H5CN-XBNM DC24 — Identification
ParameterValue
SeriesH5CN
H5CN-XBNM DC24 — Function & Modes
ParameterValue
FunctionOn-Delay
H5CN-XBNM DC24 — Timing & Counting
ParameterValue
Delay time range0.001 Sec ~ 99.99 Sec
Timing adjustment methodUp/Down Digit Keys
Timing initiate methodInput Voltage
H5CN-XBNM DC24 — Electrical
ParameterValue
Supply voltage12 ~ 48VDC
H5CN-XBNM DC24 — I/O & Contacts
ParameterValue
Contact rating @ voltage3A @ 250VAC
Contact circuit (Form)SPDT (1 Form C)
Relay typeMechanical Relay
H5CN-XBNM DC24 — Mechanical
ParameterValue
Mounting typeSocketable
Termination stylePlug In, 11 Pin (Octal)

Product details

The Omron H5CN-XBNM DC24 is an on-delay time relay from the H5CN series, set via up/down digit keys for a delay range of 0.001 to 99.99 seconds. It switches a single SPDT (1 Form C) mechanical relay contact rated at 3 A at 250 VAC. Supply voltage spans 12 to 48 VDC, and the timing initiates on application of input voltage. The octal 11-pin (plug-in) termination style means it mates with standard industrial relay sockets — common in control panels where a failed timer gets swapped in seconds without rewiring. The up/down digit keys allow precise setpoint entry, unlike trim-pot-adjusted timers that drift over temperature.

The H5CN series is a mature, broadly deployed line — not a niche or end-of-life product. For BOM freeze or PCN watch, this part is a stable selection.

Frequently asked questions

Where can I buy H5CN-XBNM DC24?

This part is sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time.

What is the closest pin-compatible alternative to H5CN-XBNM DC24?

Within the H5CN family, the H5CN-XBN (same octal 11-pin base, same SPDT contact, same delay range) differs only in supply voltage — the -XBNM variant accepts 12-48 VDC while the -XBN is fixed at 24 VAC/DC. For a direct drop-in with identical wiring, stick with the -XBNM suffix.

What is H5CN-XBNM DC24's listed series?

It belongs to the Omron H5CN series of digital time delay relays.

What is the circuit configuration?

SPDT (Single Pole Double Throw) — one Form C contact set, rated 3 A at 250 VAC.

MPN
H5CN-XBNM DC24
