On-Delay Timer, Octal Socket, Active Production
The H5CN-XDNM AC100-240: Timing range spans 1 minute to 99 hours 59 minutes, set via front-panel Up/Down digit keys — no screwdriver or DIP switch needed. Supply is 100–240 VAC, termination is a standard 11-pin octal plug that mates with an octal socket (sold separately).
The 3A @ 250VAC contact rating is resistive (AC-1 class). For inductive loads like a contactor coil or small relay, derate to roughly 1.5–2 A. The SPDT form provides one normally-open and one normally-closed set — enough to control a load and signal a PLC input simultaneously. On-delay means the output relay energizes only after the set time elapses following application of supply voltage. Timing initiate method is input voltage — apply power, the count starts. The 100–240 VAC supply covers most global line voltages without a tap change.
