The Omron H5F-FB is a programmable multi-function time delay relay from the H5F series, offering a single-pole normally-open contact rated at 15 A at 250 VAC. The delay range spans 1 minute to 24 hours, set via up/down digit keys on the front face, with timing initiated by applying the supply voltage. Supply is 100 to 240 VAC; termination is via screw terminals on a chassis-mount package. The 15 A contact rating at 250 VAC handles resistive and general-purpose loads — motor starters, contactor coils, heater banks — without an intermediate slave relay in most panel layouts.
Omron H5F-FB Time Delay Relay, 15A 250VAC, 1 Min-24 Hrs
MPNH5F-FB
Active
Omron H5F Series, Programmable Multi-Function Time Delay Relay, SPST-NO (1 Form A), 15A @ 250VAC, 100 ~ 240VAC Supply, Chassis Mount, Screw Terminal.
$162.56 – $324.51Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | H5F |
| Parameter | Value |
|---|---|
| Function | Programmable (Multi-Function) |
| Parameter | Value |
|---|---|
| Delay time range | 1 Min ~ 24 Hrs |
| Timing adjustment method | Up/Down Digit Keys |
| Timing initiate method | Input Voltage |
| Parameter | Value |
|---|---|
| Supply voltage | 100 ~ 240VAC |
| Parameter | Value |
|---|---|
| Contact rating @ voltage | 15A @ 250VAC |
| Contact circuit (Form) | SPST-NO (1 Form A) |
| Relay type | Mechanical Relay |
| Parameter | Value |
|---|---|
| Mounting type | Chassis Mount |
| Termination style | Screw Terminal |
Product details
Frequently asked questions
Where can I buy the H5F-FB and get a price?
The H5F-FB is sourced and quoted to order against an RFQ. Submit a request for quote (RFQ) through the storefront; availability and current pricing are confirmed at quote time.
What is the delay range and how is it set?
The delay range is 1 minute to 24 hours, programmable via up/down digit keys on the relay face. Timing is initiated by applying the 100–240 VAC supply voltage.
What is the contact rating on the H5F-FB?
The SPST-NO contact is rated 15 A at 250 VAC, suitable for switching resistive loads, contactor coils, and heater elements directly in most control panels.
MPN
H5F-FB
