The Omron H5S-YB2-X is a programmable multi-function time delay relay with a delay range from 1 minute up to 1 year, so it handles long-cycle timing tasks like periodic pump exercise, filter backwash scheduling, or seasonal equipment cycling without needing a separate PLC timer. Two independent SPST-NO (1 Form A) contacts, each rated 15 A at 250 VAC, give it enough beef to switch motor starters, solenoid valves, or contactor coils directly — no interposing relay needed for most industrial loads.
Omron H5S-YB2-X Time Delay Relay, 1 Min–1 Year, 15A 250VAC
MPNH5S-YB2-X
Active
Omron H5S series, programmable multi-function time delay relay, SPST-NO (1 Form A) x 2, 15A @ 250VAC, delay range 1 Min ~ 1 Year, 100 ~ 240VAC supply, panel mount, screw terminals.
$479.27 – $497.02Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | H5S |
| Parameter | Value |
|---|---|
| Function | Programmable (Multi-Function) |
| Parameter | Value |
|---|---|
| Delay time range | 1 Min ~ 1 Year |
| Timing adjustment method | Up/Down Digit Keys |
| Timing initiate method | Input Voltage |
| Parameter | Value |
|---|---|
| Supply voltage | 100 ~ 240VAC |
| Parameter | Value |
|---|---|
| Contact rating @ voltage | 15A @ 250VAC |
| Contact circuit (Form) | SPST-NO (1 Form A) x 2 |
| Relay type | Mechanical Relay |
| Parameter | Value |
|---|---|
| Mounting type | Panel Mount |
| Termination style | Screw Terminal |
Product details
Frequently asked questions
What is the delay range of the H5S-YB2-X?
The delay is adjustable from 1 minute to 1 year using the up/down digit keys on the front panel.
What is the contact rating of this time delay relay?
Each SPST-NO contact is rated 15 A at 250 VAC, sufficient for switching motor starters or solenoid valves directly.
Where can I buy the H5S-YB2-X and get current pricing?
We supply this part against an RFQ — send us your request and we'll confirm availability and current pricing at quote time.
MPN
H5S-YB2-X
